Product Details

We design our compliant modular building as a high-specification modular system that rivals traditional buildings. Moreover, it offers a long design life and delivers excellent performance that easily meets current building and energy regulations.

Additionally, we construct the module structure from a hot rolled steel ring beam incorporating galvanised steel floor joists, steel corner columns, and steel lattice roof beams. This structure provides a clear design span of up to 12m or 40ft.

On the roof, we fit 15mm tongue and grooved timber decking with a Fatra Ecopro PVC fire rated membrane, soffit roof construction, and plastic uPVC rainwater goods.

For the walls, we use timber wall studs and clad them in plastisol coated steel exterior finish. Furthermore, we provide wall insulation with Ecobrite foil therm together with 90mm fibreglass insulation. Inside, we finish the walls and ceiling with typically 12.5mm or 15mm plasterboard and UPVC architraves.

COMPLIANT MODULAR BUILDING Benefits

• 5Kn per meter square floor loading
• 0.75Kn per meter square roof loading
• Choice of Mono pitched or dual pitched roof
• End to end and side by side linking
• Choice of 2.4m, 2.7m or 3m ceiling heights
• Choice of vinyl floor covering, carpet tiles or non slip surfaces
• Standard UPVC windows with powder coated aluminum options
• Standard steel multi-point locking doors or UPVC or powder coated steel
• Option to upgrade U values depending on local regulation

Typical Uses

• Head offices
• Satellite offices
• Sports clubhouses
• Canteen and meeting facilities
• Training rooms

The price quoted is for a 3-bay open plan 32ft x 30ft compliant modular building and includes supply and delivery of the building. Final on-site installation and cranage into position is not included. Larger sizes, customisation and options available at additional cost.
